Perfect when you need a fork with long excursion.
Optimized for 160-180 mm of excursion, the 38 redefines the ability of a long excursion single crown fork, establishing a new point of reference for safety, performance and durability.
Excellent descent performance with greater traction and even more control at speed. LMore adjustable shock absorber, support and fluid focused on the descent created by Fox. A light pivot that reduces the weight, while increasing torsional rigidity and reducing L’friction among the stems of the upper and lower fork, for a more fluid race of the suspensions.
L’Equilization of pressure via button (purges) e L’increase in volume to relieve L’Increase in pressure (bypass channels) allow better sensitivity to small bumps and better reactivity.
Characteristics:
- Measure: 1-1/8 – 1.5
- Wheel: 29
- Material: aluminum
- Color: Black
- Brakes: Disc
- Hub: Pp15/110
- Excursion (mm): 170
Specifications:
- Field of use: All Mountain, Enduro
- E-Bike Ready: No
- Wheel size: 29 “
- Fork head material/handlebar attack: aluminum/aluminum
- Fork head diameter: 58 mm
- Steles material: aluminum, kashima (gold coating)
- Stems diameter: 38 mm
- Obliqui tubes material: aluminum
- Standard Axis: Boost Kabbolt-X 15×110 mm
- TUBE TUBE: 1.5 “to 1 1/8” conical (passage from 40 mm to 28.6 mm to 80 mm +/- 3 mm)
- Farm length fork: 265 mm
- Suspension excursion: 170 mm
- Suspending system: Float Air, Aria
- Spring feature adjustment: Sì, through distant volume
- Dimousing: Grip X2, closed cartridge
- Adjustment options: high -speed compression (HSC): 8 clicks | low -speed compression (LSC): 18 click | High speed rebound (HSR): 8 clicks | Rebound low speed (LSR): 16 clicks
- Locking: without
- Installation height: 583.7 mm
- Brake support: PM7, Post Mount (brake rotor min. 180 mm)
- Maximum size allowed Disc brake: 230 mm
- Maximum tire diameter: 762 mm
- Maximum pneumatic width: 2.6 “or min. 6.0 mm pneumatic space at the fork bridge
- Offset: 44 mm
- Weight: 2300g
